USB-C Male Breakout Board 24 Pin

This USB-C Male Breakout Board 24 Pin brings all the pins of a USB-C plug out to convenient pads so you can prototype, test, and integrate full-featured USB-C connectivity into your projects. Whether you are developing custom USB-C interfaces or doing hardware debugging, having direct access to all 24 USB-C pins lets you control power, data and side-band signals with confidence.

This version uses a USB-C plug instead of a receptacle, making it ideal for applications where your board needs to act as a USB device. All pins are broken out for flexibility, perfect for advanced development, prototyping rigs, and cable/pin testing.

Key Features

• USB-C male connector with full 24-pin access
• Pads for every USB-C pin for complete signal access
• Perfect for custom cable harnesses, debug setups, and prototyping
• Supports USB-C power, USB 2.0 and USB 3.x signals

What You Can Do With It

This breakout board gives you full access to:

• VBUS and GND power rails
• USB 2.0 data (D+ and D-)
• USB 3.x super-speed differential pairs
• Configuration Channel (CC) and Side-Band Use (SBU) lines

Whether you are designing custom connectors, adapting cables, or building hardware that needs to communicate over USB-C, this board makes it easy to route signals exactly where you need them.

More USB Breakout Boards

Not sure if you need full 24-pin access? We offer a range of USB breakout options to suit different project needs:

• USB-C Female Breakout Board 24 Pin - Full pin female version
• USB-C Male Breakout Board 4-Pin - Compact USB-C male without breadboard pins
• USB-A Male 4-Pin Breakout Board - Classic USB-A plug breakout

This USB-C Male 24-Pin Breakout Board is a versatile tool for custom hardware work where full USB-C signal visibility and control matter most.
