PoE Ethernet / USB HUB HAT for Raspberry Pi Zero

Waveshare  |  SKU: WS-19635
$42.15 AUD
$38.32 exc GST

Delivery and Shipping

Delivery Options

We offer several delivery choices to fit your needs:

  • FREE Delivery: $0. Enjoy Free AusPost Parcel Standard Delivery on orders over $100 in value. Exclusions may apply.
  • AusPost Untracked Letter: $3. Delivery in 3-8 business days (untracked). No refunds or replacements without proof of receiving the order.
  • AusPost Parcel Standard: $9. Tracked delivery in 2-6 business days.
  • AusPost Parcel Express: $13. Express tracked delivery in 1-3 business days.
  • Pickup: $0. Email us to arrange a pickup from our location in Huntingdale 3166 in Melbourne at support@zaitronics.com.au. More details can be found in our contact page.

Additional Information

  • Non-metro addresses in WA, NT, SA & TAS may require extra time.
  • Certain batteries (like LiPo) cannot be shipped by air, affecting Express Post availability.
  • We recommend selecting tracked options for valuable items. Untracked orders will not receive tracking numbers or refunds without proof of delivery.
  • Note: Wherever possible, we will combine orders to save on shipping and reduce packaging waste.
  • Note: Orders containing backordered item will delay delivery until all items are available

Warranty & Refund Policy

Warranty & Refund Policy

  • Standard Warranty: 12 months for all products. Low-cost hobby parts have a 90-day warranty unless safe handling is shown.
  • Exceptions: Kits and interfaceable electronics may not be covered if damaged due to misuse.
  • Returns: Contact support via your order confirmation email within 14 days of purchase. Items must be unopened and in original packaging. Proof of purchase is required.
  • Defective/Damaged Items: Notify us within 30 days for a free refund or replacement. Exclusions apply.
  • Return Shipping Costs: Paid by the customer unless the item is defective. Shipping costs are non-refundable.
Features at a glance

The PoE/ETH/USB HUB HAT is a PoE (Power over Ethernet) USB HUB HAT designed for Raspberry Pi Zero. By using this small HAT and some proper 802.3af-compliant power sourcing equipments, it is possible to provide both network connection and power supply for your Raspberry Pi in only one Ethernet cable, along with 3x extended USB ports.

  • Designed for Raspberry Pi Zero, compatible with Zero series boards
  • Incorporates RTL8152B Ethernet chip, with 10M / 100M auto-negotiation RJ45 port
  • PoE (Power over Ethernet) feature, 802.3af-compliant
  • Fully isolated SMPS (Switch Mode Power Supply)
  • 3x extended USB ports, compatible with USB 2.0 / 1.1
Specifications
PoE power input 37V ~ 57V DC in
Power output 5V 2.5A DC out
Network standard IEEE 802.3af-compliant PoE
Dimensions 23.10 × 65.00 mm
Compatible with Raspberry Pi Zero series

Designed for Raspberry Pi Zero, compatible with Zero / Zero 2W / Zero W / Zero WH

Wiki: PoE/ETH/USB_HUB_HAT
