ESP32-S3 AIoT Camera Development Board + OV3660 Camera
ESP32-S3 AIoT Camera Development Board + OV3660 Camera has a 5-10 day lead time before dispatch. Order will only be sent once all items are available for delivery.
ESP32-S3 AIoT Camera Development Board + OV3660 Camera
The ESP32-S3 AIoT Camera Development Board with OV3660 Camera is a compact, feature-rich AI development platform designed for computer vision, voice interaction, and IoT applications. Powered by the ESP32-S3 dual-core microcontroller, it combines wireless connectivity, camera support, audio processing, battery management, and display interfaces into a single board, making it ideal for AI-powered smart devices and edge computing projects.
Supporting online AI platforms such as DeepSeek and Doubao, as well as Edge Impulse object detection, the board enables applications including voice assistants, image recognition, smart cameras, HMI displays, and AIoT terminals. With onboard PSRAM, Flash memory, dual microphones, battery charging circuitry, and multiple expansion interfaces, it provides everything needed for rapid AI application development.
Features
- Powered by the ESP32-S3 dual-core Xtensa LX7 processor running at up to 240MHz
- Supports 2.4GHz Wi-Fi and Bluetooth Low Energy (BLE)
- 16MB onboard Flash memory and 8MB PSRAM
- 512KB SRAM and 384KB ROM
- Includes OV3660 camera module with 24-pin DVP camera interface
- Compatible with AI platforms including DeepSeek, Doubao, and Edge Impulse
- Supports real-time object detection and AI vision applications
- Dual microphones with noise reduction and echo cancellation for voice recognition
- ES8311 audio codec and ES7210 audio processor
- SPI/QSPI LCD interface for external displays
- USB Type-C for programming and power
- TF (MicroSD) card slot for additional storage
- Onboard lithium battery charging circuit supporting 3.7V Li-ion/LiPo batteries
- Speaker output header with onboard amplifier
- I2C and UART expansion headers
- Onboard ceramic antenna with IPEX connector for an external antenna
- Dedicated BOOT and Power buttons
- Highly integrated design for AIoT, computer vision, and embedded development
Applications
- AI vision and object detection
- Smart cameras
- Voice assistants
- Human-machine interface (HMI) devices
- Face and object recognition
- IoT edge computing
- Home automation
- Robotics
Specifications
| Microcontroller | ESP32-S3 |
|---|---|
| CPU | Dual-core Xtensa LX7, up to 240MHz |
| Wireless | 2.4GHz Wi-Fi and Bluetooth LE |
| Flash Memory | 16MB |
| PSRAM | 8MB |
| Internal Memory | 512KB SRAM, 384KB ROM |
| Camera | OV3660 |
| Camera Interface | 24-pin DVP |
| Display Interface | SPI / QSPI LCD |
| Storage | TF (MicroSD) card slot |
| Battery Support | 3.7V Li-ion/LiPo with onboard charging |
Interface Definition
Dimensions
What's On Board
Documentation: ESP32-S3 AIoT Camera Wiki
