USB-C Breakout Board 4 Pin

This USB-C Breakout Board 4 Pin provides a compact, straightforward way to add USB-C connectivity to your electronics projects. With a female USB-C receptacle and 2.54mm spaced pins, it's designed for breadboard prototyping and integration into custom circuits where space is at a premium.

The board breaks out the essential USB connections, VBUS, GND, D+, and D-, giving you everything needed for USB 2.0 power and data in a minimal footprint. It's ideal for projects that need basic USB-C functionality without the complexity of additional pins or features.

How It Works

The USB-C receptacle includes 5.1K resistors on the CC pins, which signal to the upstream device to provide 5V power at up to 1.5A (actual current depends on the source). Simply connect VBUS to your 5V input, GND to ground, and use D+ and D- for USB 2.0 data communication. The compact 4-pin design keeps your circuit simple and your board space efficient.

Features

• Female USB-C receptacle for standard USB-C cables
• Breaks out VBUS, GND, D+, D- on 2.54mm pitch pins
• Breadboard and perfboard compatible

• Ultra-compact footprint for space-constrained designs
• Supports USB 2.0 data and up to 1.5A power delivery

Typical Applications

• Compact prototyping projects
• USB-C power input for microcontroller projects
• Space-constrained embedded systems
• Educational electronics and maker projects
• USB 2.0 communication interfaces

Need More Features or Pins?

Explore our expanded USB-C breakout options for additional capabilities:

• USB-C Breakout Board 6 Pin - Adds CC and SBU pin access for advanced applications
• USB-C Female Breakout Board 24 Pin - Complete pin access for full USB-C capabilities
• USB-C Panel Mount Breakout Board 4 Pin - Panel-mount version for enclosure integration

This 4-pin breakout is the perfect choice when you need simple, reliable USB-C connectivity in the smallest possible package.
